A web application for a DIY amateur observatory with support for remote monitoring, equipment management, weather data, and an astrophoto archive. Developed using PHP, MariaDB, Next.js, React, Redux RTK, SASS, and TypeScript. Please give the project a star :)

Homemade Observatory Web Application

Changelog · Demo · Contact

---

Table of Contents

• About the Project
  • Key Features
  • Built With
• Project Structure
• Getting Started
  • Prerequisites
  • Database
  • Backend Setup
  • Frontend Setup
• Configuration
  • Frontend Environment Variables
  • Backend Environment Variables
• API Overview
• Deployment
• Contributing
• License
• Contact

---

About the Project

Amateur Astronomy Observatory Portal is a DIY platform for managing and monitoring a remote observatory. The web app consists of several user screens, including displaying telemetry from the observatory, a weather station, storing processed astronomy photos, and storing information about captured frames. The app also features an interactive sky map, a deep sky image archive, and a live dashboard with weather and equipment statistics. The portal combines automation with practical astrophotography. Whether you are tracking celestial events or analyzing FITS footage, this project demonstrates the convergence of technology and astronomy.

Key Features

• Built with React and Next.js — a fast and scalable web application for managing astronomical data.
• Interactive Celestial Map — explore observed objects, constellations, stars, and their imaging history powered by Celestial.js and D3.js.
• Real-Time Observatory Dashboard — monitor telescope status, weather conditions, and sensor data live.
• Astrophotography Archive — FITS file management and astrophotography archive with detailed metadata, equipment info, and filters.
• Stargazing Events — event management with registration, check-in via QR code, and photo upload.
• Astronomy Calculations — visibility charts, celestial coordinate utilities, moon phase display using astronomy-engine and suncalc.
• Remote Observatory Control — manage equipment power and receive telemetry via an Arduino-based controller.
• OAuth Authentication — sign in with Google, Yandex, or VK accounts.
• Telegram Integration — astronomy news and expedition reports synced with a Telegram channel.
• Multilingual UI — i18n support via i18next.

(Back to top)

---

Built With

The Homemade Observatory Web Application project leverages a wide range of technologies across various layers of the system:

• Server-side scripting language (PHP 8.2) powering the CodeIgniter 4 backend API.
• MariaDB/MySQL database system for storing all application data.
• Core language used in frontend development.
• TypeScript extends JavaScript by adding types to the language (v5.9.3).
• React-based frontend framework for building the user interface (v16.1.6).
• State management for the frontend via Redux Toolkit with RTK Query.
• JavaScript runtime used for frontend development and package management (≥20.11.0).
• Styling the user interface.
• Continuous integration and deployment pipeline for automating tests and deployment processes.
• Code quality and security analysis.

(Back to top)

---

Project Structure

This is a monorepo with three independent subsystems:

astronomy-portal/
├── client/              # Next.js 16 frontend application
│   ├── api/             # RTK Query API layer and data models
│   ├── components/      # React UI components
│   ├── pages/           # Next.js pages-router (routes)
│   ├── public/          # Static assets, star map data, images
│   └── utils/           # Utility functions (coordinates, dates, moon, etc.)
├── server/              # CodeIgniter 4 PHP backend API
│   └── app/
│       ├── Controllers/ # Request handlers (Auth, Photos, Events, Objects…)
│       ├── Models/      # Database models extending ApplicationBaseModel
│       ├── Entities/    # DB row entity classes
│       ├── Database/
│       │   └── Migrations/ # Database migrations
│       ├── Config/      # Routes, CORS, Filters, Services
│       └── Libraries/   # JWT, Telegram, Locale helpers
├── firmware/            # Arduino firmware for observatory hardware control
│   └── main/
└── config/              # Docker Compose and Nginx configuration

(Back to top)

---

Getting Started

Prerequisites

Tool	Version
Node.js	≥ 20.11.0
Yarn	4.9.2
PHP	≥ 8.2
Composer	≥ 2.x
Docker & Docker Compose	any recent version

---

Database

The project uses MariaDB. Start a local instance via Docker Compose:

cd config
docker-compose up -d

This starts a MariaDB 10.5.8 container accessible at localhost:3308 with:

• Database: db
• User: user
• Password: password

---

Backend Setup

cd server

# Install PHP dependencies
composer install

# Copy environment file and configure it
cp .env.example .env

# Run database migrations
composer migration:run

# (Optional) seed initial data
composer seed:run

# Start development server at http://localhost:8080
composer serve

---

Frontend Setup

cd client

# Install Node.js dependencies
yarn install

# Copy environment file and configure it
cp .env.example .env

# Start development server at http://localhost:3000
yarn dev

To build for production:

yarn build

(Back to top)

---

Configuration

Frontend Environment Variables

Variable	Description	Example
NEXT_PUBLIC_SITE_LINK	Public URL of the frontend	http://localhost:3000/
NEXT_PUBLIC_API_HOST	Backend API base URL	http://localhost:8080/
NEXT_PUBLIC_IMG_HOST	Base URL for serving uploaded images	http://localhost:8080/
NEXT_PUBLIC_LAT	Observatory latitude (for sky map)	51.7
NEXT_PUBLIC_LON	Observatory longitude (for sky map)	55.2

Backend Environment Variables

Variable	Description	Example
CI_ENVIRONMENT	App environment (development / production)	development
app.baseURL	Backend base URL	http://localhost:8080/
app.appTimezone	Server timezone	Asia/Yekaterinburg
app.latitude	Observatory latitude	51.7727
app.longitude	Observatory longitude	55.0988
app.fitsApiKey	API key for FITS data source	—
app.telegramBotKey	Telegram bot token	—
app.telegramChatID	Telegram channel/chat ID	—
app.observatory.controller	URL of Arduino relay controller	http://astro.myftp.org:8081/
app.observatory.webcam_1	Webcam 1 snapshot URL	—
app.observatory.webcam_2	Webcam 2 snapshot URL	—
auth.token.secret	JWT secret key	—
auth.token.live	JWT lifetime in seconds	1209600
auth.google.*	Google OAuth credentials	—
auth.yandex.*	Yandex OAuth credentials	—
auth.vk.*	VK OAuth credentials	—
database.*.hostname	DB host	127.0.0.1
database.*.port	DB port	3308
database.*.database	DB name	db
database.*.username	DB user	user
database.*.password	DB password	password

(Back to top)

---

API Overview

All backend endpoints are defined in server/app/Config/Routes.php.

Method	Endpoint	Description
GET	/auth/me	Current authenticated user info
GET	/auth/google	OAuth via Google
GET	/auth/yandex	OAuth via Yandex
GET	/auth/vk	OAuth via VK
GET	/equipments	Observatory equipment list
GET	/categories	Photo categories list
GET|POST|PATCH|DELETE	/objects/:name	Astronomical objects CRUD
GET	/fits/:name	FITS file data for an object
GET|POST|PATCH|DELETE	/photos	Astrophoto archive CRUD + upload
GET|POST|PATCH	/events	Stargazing events management
POST	/events/booking	Book a place at an event
POST	/events/cancel	Cancel booking
POST	/events/checkin	QR check-in
GET	/events/members	Event member list
GET	/events/upcoming	Upcoming events
GET	/relay/list	Relay devices list
GET	/relay/light	Observatory light status
PUT	/relay/set	Set relay state
GET	/statistic/telescope	Telescope usage statistics
GET	/files/:path	File serving
GET	/sitemap	Sitemap data
GET	/system/recalculate/fits	Recalculate FITS filters

(Back to top)

---

Deployment

CI/CD is handled by GitHub Actions (.github/workflows/):

Workflow	Trigger	Action
ui-checks.yml	Pull Request	Lint + test + build frontend
ui-deploy.yml	Push to main	Deploy frontend via SSH/rsync to VPS, served with PM2
api-deploy.yml	Push to main	Deploy backend via FTP to shared PHP hosting
sonarcloud.yml	PRs + push to main	SonarCloud quality gate

The frontend is built as a Next.js standalone app (output: 'standalone' in next.config.js) and managed by PM2 (ecosystem.config.js).

(Back to top)

---

Contributing

Contributions are what make the open-source community an incredible environment for learning, inspiration, and innovation. Your contributions are highly valued and greatly appreciated, whether it's reporting bugs, suggesting improvements, or creating new features.

To contribute:

1. Fork the project by clicking the "Fork" button at the top of this page.
2. Clone your fork locally:

   git clone https://github.com/miksrv/astronomy-portal.git

3. Create a new feature branch:

   git checkout -b feature/AmazingFeature

4. Make your changes, then commit them:

   git commit -m "Add AmazingFeature"

5. Push your changes to your forked repository:

   git push origin feature/AmazingFeature

6. Open a pull request from your feature branch to the main repository.

We encourage contributions of all kinds, whether big or small. Your efforts help improve the project for everyone!

(Back to top)

---

License

Distributed under the MIT License. See LICENSE for more information.

(Back to top)

---

Contact

Misha - miksoft.pro
